STORM 27.5

Frameset

Frame - Aluminum, Tig Welding, 10x135mm QR, Tapered HT

Fork - Suntour XCT-30 DS Coil, 100mm, 46mm offset, 9x100 QR

Drivetrain

Rear Shifter - Shimano Cues SL-U4000, 9sp

Rear Derailleur - Shimano Cues RD-U4000, 9sp, GS

Crankset - Prowheel Alloy, 30T, 155mm

Bottom Bracket - Cartridge, ST 73mm, 113mm axle length

Cassette - Shimano Cues CS-LG300-9, 9sp,11-46TChainKMC Z9Brakes

Front Brake - Tektro HD-M276, Resin pads

Front Brake Rotor - Tektro. 160mm rotor, 6-bolt

Rear Brake - Tektro HD-M276, Resin pads

Rear Brake Rotor - Tektro. 160mm rotor, 6-bolt

Brake Levers - Tektro HD-M276 w/Jr Lever

Components

Handlebar - 6061 Alloy DB 6.1, 720mm, 30mm rise

Stem - Alloy 50mm Length, 31.8mm Clamp

Seatpost - Alloy 31.6mm, 300mm length

Headset - Zero Stack, 1-1/8" Steer, ZS44/28.6 | ZS44/30 1 1/8"

Headset Spacer - 3x10mm

Saddle - Norco Jr XC, Steel Rail

Grips - DDK lock-On, 139mm length

Pedals - Nylon Flat Pedal

Seatpost Clamp - Norco Alloy QR, 34.9mm ID

Wheels

Front Hub - Formula DC-1420 , 9x100mm QR, 32h, 6-bolt

Rear Hub - Formula DC-1422,10x135mm QR, HG, 32h, 6-bolt

Rims - DP 27 Rims, 27mm ID, 32H

Front Tire - Maxxis Forekaster, 27.5x2.25", Wire

Rear Tire - Maxxis Forekaster, 27.5x2.25", Wire

Spokes/Nipples - Stainless Steel, 14g
